High-precision granite
Granite Platform
- Features
- Major Guarantees:
- ※ Precision Assurance of Taiwan Manufacturing
- ※ Stable Precision and Superior Wear Resistance
- ※ Utilization of Indian Black Granite Material for Material Assurance
Description
Granite Platform/Made in Taiwan
Features:
1.Made of natural granite material, ensuring stability of performance and dimensions.
2.Excellent processing capabilities: sawing, cutting, polishing, drilling, carving, etc. Its processing accuracy can reach below 0.5μm, with a glossiness of over 100 degrees.
3.Excellent wear resistance, 5-10 times higher than cast iron.
4.Small thermal expansion coefficient, not easily deformed, similar to Invar steel, minimal temperature influence.
5.High elastic modulus, higher than cast iron.
6.Manufacturing accuracy standard: conforms to German DIN876.
Specifications
| 000 grade | 00 grade | 0 grade | |||||
|---|---|---|---|---|---|---|---|
| (L*W*T) mm | (KG) | Accuracy (um) |
Model No. | Accuracy (um) |
Model No. | Accuracy (um) |
Model No. |
| 300*300*50 | 1.3 | TSA 300*300-000 | 2.6 | TSA 300*300-00 | 5.2 | TSA 300*300-0 | |
| 300*450*60 | 1.45 | TSA 300*450-000 | 2.9 | TSA 300*450-00 | 5.8 | TSA 300*450-0 | |
| 450*450*60 | 1.45 | TSA 450*450-000 | 2.9 | TSA 450*450-00 | 5.8 | TSA 450*450-0 | |
| 450*600*80 | 1.6 | TSA 450*600-000 | 3.2 | TSA 450*600-00 | 6.4 | TSA 450*600-0 | |
| 500*750*100 | 1.75 | TSA 500*750-000 | 3.5 | TSA 500*750-00 | 7 | TSA 500*750-0 | |
| 600*600*100 | 1.6 | TSA 600*600-000 | 3.2 | TSA 600*600-00 | 6.4 | TSA 600*600-0 | |
| 750*750*120 | 1.75 | TSA 750*750-000 | 3.5 | TSA 750*750-00 | 7 | TSA 750*750-0 | |
| 600*900*120 | 1.9 | TSA 600*900-000 | 3.8 | TSA 600*900-00 | 7.6 | TSA 600*900-0 | |
| 900*900*150 | 1.9 | TSA 900*900-000 | 3.8 | TSA 900*900-00 | 7.6 | TSA 900*900-0 | |
| 900*1200*160 | 2.2 | TSA 900*1200-000 | 4.4 | TSA 900*1200-00 | 8.8 | TSA 900*1200-0 | |
| 1000*1000*160 | 2 | TSA 1000*1000-000 | 4 | TSA 1000*1000-00 | 8 | TSA 1000*1000-0 | |
| 1000*1500*200 | 2.5 | TSA 1000*1500-000 | 5 | TSA 1000*1500-00 | 10 | TSA 1000*1500-0 | |
| 1000*2000*260 | 3 | TSA 1000*2000-000 | 6 | TSA 1000*2000-00 | 12 | TSA 1000*2000-0 | |
| 1200*1500*220 | 2.5 | TSA 1200*1500-000 | 5 | TSA 1200*1500-00 | 10 | TSA 1200*1500-0 | |
| 1200*2000*280 | 3 | TSA 1200*2000-000 | 6 | TSA 1200*2000-00 | 12 | TSA 1200*2000-0 | |
| 1500*3000*400 | 4 | TSA 1500*3000-000 | 8 | TSA 1500*3000-00 | 16 | TSA 1500*3000-0 | |
| Using high-quality granite slabs, precision refers to various advanced country standards, with flatness tolerances according to DIN876 standard for rock slab standards: Metric precision calculation formulas: (where L is the length of the longest side)000 Grade formula = 1 + (L/1000) μm, Surface roughness Ra 0.4 μm00 Grade formula = 2 + (L/500) μm, Surface roughness Ra 0.8 μm0 Grade formula = 4 + (L/250) μm, Surface roughness Ra 1.6 μm We reserve the right to alter the Specifications |
|||||||
