FILE NAME DESCRIPTIONS FILE SIZE DOWNLOAD
Large vision VMM 1.Custom Stitching View: Customize the stitched image view. 2. Field of View Setting: Set the field of view, measure the entire area for a single file creation. 3. Multi-Workpiece Measurement: Measure multiple workpieces at the same time. 4. Quick Stitching: Stitch a 200 mm x 200 mm image within 40 seconds. 373.32KB download
VMM 1) Video Measuring Machine, VMM loads high accuracy with fixed working table and granite pedestal. 2) RS-232 interface can do communication between measuring software and computer. 3) Optional : High resolution Japan 1/2" color CCD camera with sharp images. 4) The user can manage and output the graphs as bmp or DWG format by connecting with PC and running the program. 5) One-click edge detection. 2.46MB download
High precision granite ※ Precision Assurance of Taiwan Manufacturing ※ Stable Precision and Superior Wear Resistance ※ Utilization of Indian Black Granite Material for Material Assurance 813.24KB download
Profile Projector 1.Excellent optical measuring system to project precisely magnified image in Profile Projector. 2.Magnification accuracy : 0.08% contour, 0.12% surface. 3.Equipped with 3M DRO(DC3000) data processing system and foot-switch for measuring. 4.Erect image measuring for different requirements. 2.41MB download
Instant Blink Measurement Introducing our advanced imaging system for fast, precise measurement. After setup, simply place the workpiece on the machine—no alignment or extra buttons required. Our software automatically measures with high accuracy, even with random placement. This hands-free system reduces setup time and eliminates manual adjustments, ideal for manufacturers seeking precision and ease. Experience cutting-edge automated measurement technology. 1.78MB download
Horizontal Instant VMM 360-degree rotating platform Single program for comprehensive, angle-free measurement Specialized for tools and lathe parts Instant measurement of hundreds of dimensions Equipped with SPC statistical system 1.41MB download
Linear scale 1. Superior Quality and Accuracy 2. Unmatched Reliability and Durability 3. Exceptional Anti-Jamming and Environmental Resistance 4. Reliable Maintenance and Longevity 5. Comprehensive After-Sales SupportExperience Precision Like Never Before 1.5MB download
DRO SW4000： 1. **Wide Voltage Range**: AC 90V - 240V with low power consumption (max 15W). 2. **High Precision Resolution**: Adjustable from 0.1μm to 50μm. 3. **Versatile Functionality**: Includes coordinate zero setting, ½ calculation, and ABS/INC conversion. 4. **Advanced Machining**: Supports bolt circle, R-angle, oblique line drilling, and more. 5. **Data Retention & Error Compensation**: Instant power failure memory and linear error compensation. 2.01MB download
Height measuring machine 1. Granite air flotation mechanical structure- high accuracy and small deformation by temperature difference. 2. Auto measuring- high efficiency,and high stability and reliability. 3. Verticality measurement available upon request 4. Air flotation in pedestal,which makes it convenient to measure. 2.15MB download
Video Digital Tool-maker Microscope 1. VDTM series video toolmaker microscopes have many functions such as data gathering/displaying, image displaying/magnifying, data input/output. 2. Equipped with professional inspection color CCD camera and image measuring software greatly enhances image measurement performance, it make the operation of edge detection faster and more accurate. 3. Eyepiece system can perform good optical view and the illumination is much clearer then VMM. 4. VDTM can also connect to PC by RS232 interface on digital readout device. It can input and output the measured values directly. 591.61KB download
